TECHNICAL SPECIFICATIONS：

Input Voltage:90-260V, 50-60 Hz

Led Source:1*300W 8000K white LED, 50000 hours life span and low power consumption

16*10W RGBW CREE Leds

Power Consumption:500W

Protocol:USITT DMX-512

Channels:18 / 25 DMX channels with RDM

Pan movement:540°(16bit fine)Tilt movement:270°(16bit fine)

Advanced moving system:Scan position memory, auto reposition after unexpected movement

fast, stable and quiet, auto X-Y repositioning

Use a three-phase motor, fast, quiet, with automatic error correction and reset

Beam Angle:3°

Strobe:Variable from 1-25 flashes or random strobe

Color wheel:7 colors + Open, halfcolor and rainbow effect

Fixed gobo wheel:8 fixed gobos+open and bi-direction rotation

Rotating gobo:7 interchangeable, rotating, indexable, gobos+open,

Prism:A linear prism & a 16 prism and a honeycomb prism, can be superimposed, variable speed rotation Flicker-free operation

Control Mode:DMX512, master-slave and sound activated or auto operation

Dimming:0-100% Smooth linear LED dimmer

Controls:2.8" TFT LCD touch display (320*240pix) with 4 control buttons

LCD display switch-off automatically after 60 seconds

Lower noise and efficient FAN cooling system

Temperature protection function: when the device temperature reaches 40, the fan starts to rotate, when the device reaches 70°

Focus:motorized focus

Frost:fine wash effect

Power Connectors:PowerCon™ compatible in/out power connectors

DMX Connectors:3-pin DMX input/output (5-pin DMX is available)

Light Housing:Durable plastic composite housing

Use Indoor IP20 for stage, event, DJ shows, etc

Fixture size:330*230*560 mm

N.W.15.8kg
