Technical Parameter

Light source:Main light: 1080*1W 3535 white light beads

• Auxiliary lighting: 600*0.5W 5050RGB lamp beads

Other Effect

• Outstanding color mixing effect

• Dimming： 0%-100% smooth dimming

• strobe:0-30Hz

• 4x single strobe lines covered by elliptical lenses

Control

• Channel mode:15CH / 39CH / 71CH / 112CH / 178CH / 209CH / 275CH

• Control protocols: DMX512, RDM, Art-Net, SACN

• Software upgrade: Upgrade the software via DMX connection

• Display: LED display screen

• 4 touch button control panel

Electrical & Interface

• Input supply: AC100-240V~, 50/60Hz

• power: 700W

• Power In/Out: Waterproof power connector in/out

• Data In/Out: 3-pin or 5-pin waterproof XLR,RJ45 connector

Work Environment

• Max Ambient Temperature: 40°C

• Mini Operating Temperature: -10°C

• Protection Rating: IP65

Fixture Dimensions:

• Size: 500*180*290mm

• Net Weight: 10 kg
